Lyra 6
Share2-pipe heat pumps - R32 - FGI
-
COP 4,64
-
MODULATION 1:9
-
DHW 55°
-
HEATING WATER
-
OPERATING RANGE -22°C / +45°C
-
ENERGY EFFICIENCY CLASS
Technical specifications
Technical Documentation
Energy documentation
Request info
Two-pipe heat pump with system-side heat exchanger, able to produce hot or cold water to meet the building's heating or cooling requirements, depending on the season, and DHW.
- Electronic expansion valve (suitable for all operating situations)
- Units with modular power output, thanks to inverter technology
- Climate control included with outdoor temperature sensor
- Larger heat-exchange surface
Energy efficiency class
All versions of Lyra Monobloc 2T are energy class A+++/A++ and therefore benefit from tax deductions in accordance with applicable legislation.
Components
- EC fan
- Twin Rotary Compressor
- Finned pack with hydrophilic treatment
- Heat exchanger with larger rows, large heat-exchange surface
Where can it be installed?
- Suitable for new buildings with high levels of energy efficiency
- Suitable for cold climates such as mountain areas and high T production up to 60°
- Ideal where no mains GAS supply is available
- Suitable for applications with radiant systems, fan coils, thermal ventilation and AHUs
Summer operation
The summer operating modes are:
- Chiller mode
The unit produces only chilled water for the system. - Boiler mode for the production of domestic hot water
If there is no cold load and on request by the domestic hot water probe, the unit heats the water in the domestic hot water storage tank using the finned pack coil as an evaporator. The use of warm outside air as a heat source guarantees extremely high COP levels.
Winter operation
The winter operating modes are:
-
Heat pump mode for heating: the unit produces hot water at the system side heat exchanger for heating.
- Heat pump mode for the production of domestic hot water: High temperature hot water is produced at the heat exchanger connected to the domestic hot water storage tank.
Automatic seasonal regulation
The system switches automatically between the various operating modes according to a priority logic for the production of domestic hot water.
Technical specifications
Cooling
Summer operation A35/W7
Cooling Capacity Min.
kW
2.37
Cooling Capacity Nom.
kW
3.68
Cooling Capacity Max.
kW
5.03
Power input
kW
1.24
E.E.R.
2.96
Water flow rate
m³/h
0.6
Useful head
mca
6.2
Summer operation A35/W18
Cooling Capacity Min.
kW
3.11
Cooling Capacity Nom.
kW
4.98
Cooling Capacity Max.
kW
7.03
Power input
kW
1.24
E.E.R.
4
Water flow rate
m³/h
0.86
Useful head
mca
6
Heating
Winter operation A7/W35
Heat output Min.
kW
2.72
Heat output Nom.
kW
4.33
Heat output Max.
kW
5.81
Power input
kW
0.93
C.O.P.
4.64
Water flow rate
m³/h
1
Useful head
mca
5.7
Winter operation A7/W45
Heat output Min.
kW
2.59
Heat output Nom.
kW
4.14
Heat output Max.
kW
5.58
Power input
kW
1.13
C.O.P.
3.67
Water flow rate
m³/h
0.71
Useful head
mca
6
Energy data
ERP
Energy efficiency Water 35°C
A+++
Energy efficiency Water 55°C
A++
Energy Efficiency
SCOP 35° C
4.03
SCOP 55° C
2.67
Compressor
Type
Twin Rotary
Number of compressors
1
Refrigerating circuits
1
Refrigerant
Type
R32
Coolant load
kg
1.08
Outdoor fan
Number
1
Air flow rate
m³/h
3579
Useful head
mca
20
Power input
kW
0.05
Internal exchanger
Internal exchanger type
With brazewelded plates
Number of internal exchangers
1
Water volume
l
0.7
Hydraulic circuit
Maximum water side pressure
bar
3
Water connections
1”
Maximum circulator power
kW
0.06
Noise emissions
Sound power (1)
dB(A)
43
Sound power (2)
dB(A)
58
Sound pressure at 5 m
dB(A)
33
Sound pressure at 10 m
dB(A)
27
Electrical data
Supply
V/Ph/Hz
230-1-50
Maximum power input
kW
2.3
Maximum absorbed current
A
11.31
Dimensions
W x H x D
mm
1000 x 735 x 443
Machine data
Weight
kg
85
Technical Documentation
Depliant
User terminal manual
Installation Manual
Technical and Maintenance Manual
Connection diagram
Functional diagram LYRA + HYDROBLOCK
FUNCTIONAL DIAGRAM LYRA 2T MB IN CASCADE + PUFFER + EASY TOUCH AND RADIANT FLOOR HEATING
FUNCTIONAL DIAGRAM LYRA 2T MB + DHW + EASYTOCH + SOLAR
FUNCTIONAL DIAGRAM LYRA 2T MB + PUFFER + PGD AND RADIANT FLOOR HEATING
Wiring diagram Lyra 6 e 8 kW 230 V
Dimensional LYRA 06 - 08 kW
Energy documentation
EC declaration of comformity 2024/2025
Energy label LYRA 06
